Rubber Conveyor Belts-Grade M24

Specially compounded rubber cover grade recommended for handling moderately abrasive material to the maximum abrasion loss value specificed for grade like sized coal, ash, chalk, bauxite etc. as per international standards IS 1891 (Part-1). Ricky Rubber Enterprise is a well-renowned brand in the belting industry which yields general duty belt manufacturer in the market. Grade M24 belts are generally utilized in law enforcement or security. These belt are high in resistant abrasion and are designed in such a manner that it delivers exceptional results and performance in the given end usage environment.


general-purpose-belting-M24
Physical Properties
Before Ageing After Ageing
Standard Tensile Strength MPa Elongation % Temperature of Ageing ºC Duration of Ageing hours Change in Tensile Strength % Change in Elongation % Maximum Abrasion Loss mm3
IS 1891 PART-I BS 490 PART-I ISO 4195/1 DIN 22102 24 450 70 72 +10-20 +10-25 150

M24 - Our range of M24 (24MPa) Conveyor Belts are abrasion resistant and highly resistant to cuts and gouges. These are mainly used in all mining industries and process industries such as cement (limestone), steel (crushed metallic ores), stone crushing industries (granite & blue metal).


Grade M24 Rubber Conveyor Belts are also considered in General Purpose Belting and these are used in industries like Mining Industries and Process Industries i.e:

Broken glass / cullet
Cement, concrete plants
Power plants , garbage incineration plants
Road construction machinery
Sand, gravel, stone industry
Recycling, compost industry, mineral processing plants

Key Features of Grade M24 Rubber Conveyor Betls

  • Anti-tear and rip resistant qualities without any equivalent in conventional fabric conveyor belts.
  • Special Steel wefts with high elongation and tensile strength properties arranged at a nominal pitch.
  • To break the ripping momentum; limiting any longitudinal cutting and tearing.
  • Superior carcass protection through greater impact energy distribution across the belt width.
  • Exceptional fastener-holding ability if required.
  • Pulley system modifications not required; transversal steel/fabric weft has no influence.
  • Longer service life under heavy-duty applications manufactured to DIN standards.
